Thermal images, or thermo grams, are actually visual displays of the amount of infrared
energy mitted, transmitted, and reflected by an object. Because there are multiple sources of the infrared energy,
it is difficult to get an accurate temperature of an object using this method. A thermal imaging camera is
capable of performing algorithms to interpret that data and build an image. Although the image shows the viewer
an approximation of the temperature at which the object is operating, the camera is actually using multiple
sources of data based on the areas surrounding the object to
determine that value rather than detecting the actual temperature
Scope Of Work
Work site evaluation and equipment to categorization.
Checking of materials and components like transformer and electrical connections
Find the broken insulation.
Damaged insulation in cables.
High friction spots in electric motors.
★Connectivity High resistance
★Corroded connections and internal fuse damage.
★Internal circuit breaker faults
★Poor connections and internal damage
Thermal Sensitivity Accuracy
